Features of air unit

AIR UNITS	TOBERA	GEAR BOX	PROPELLER	NOZZLE-HOLDERS*	HIGHEST FLOW RATE
STU6/STUV6	ø610 mm	1 speed + neutral point	8 variable pitch blades	12 pulv. OGC	21.600 m³/h
STU7	ø750 mm	2 vel + PM	8 variable pitch blades	14 pulv. ADOGC	44.800 m³/h
STUV7	ø765 mm	2 vel + PM	8 variable pitch blades	14 pulv.	49.500 m³/h
STU8	ø820 mm	2 vel + PM	8 variable pitch blades	14 pulv. ADOGC	53.500 m³/h
STUV8	ø815 mm	2 vel + PM	8 variable pitch blades	14 pulv.	56.550 m³/h

*PORTABOQUILLAS
OTC: orientable, turning with stopcock closing device.
ADSTC: antidripping, double, steerable, turning with stopcock closing device.

Equipment

FRAME

Reinforced frame, designed in steel plate and laser-manufactured, which allow us its chain production and a perfect result, providing this with utmost stiffness.

MIXING

Two levels of mixing (pressure/return) which achieve a constant and homogeneous mixture.

TANKS

In high density polyethylene.
Capacities: 800 and 1.000l.
Rinsing auxiliary tank (10%) according to CE rules and sanitary water tank.

FILTERING

3 Levels of filtering

1 BASKET Filter in the filling mouth of the tank.
1 pump suction Filter
1 pressure Filtering Central
